Description / توضیحات
Model 1771-SDN
Module location SLC 5/02 or later chassis
Module defaults
Node Address 63
Baud Rate 125 Kbps
Power consumption
- Backplane current
- DeviceNet
5V DC, 500 mA
24V DC, 90 mA Class 2
Isolation voltage
30V (continuous), Basic Insulation Type
Tested at 500V AC for 60 s, DeviceNet to backplane
Temperature, operating
IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
0...60?C (32...140?F)
Temperature, non-operating
IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bc, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40...85?C (-40...185?F)
Relative humidity
IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5 95% non-condensing
Vibration
IEC60068-2-6 (Test Fc, Operating):
2 g @10 500 Hz
Shock
Operating 30 g
Non-operating 50 g
Emissions
CISPR 11:
Group 1, Class A (with appropriate enclosure)
ESD immunity
IEC 61000-4-2:
6 kV contact discharges
8 kV air discharges
Radiated RF immunity
IEC 61000-4-3:
10 V/m with 1 kHz sine-wave 80% AM from 80 2000 Mhz
EFT/B immunity
IEC 61000-4-4:
+2 kV at 5 kHz on communication ports
Surge transient immunity
IEC 61000-4-5:
?2 kV line-earth(CM) on communications ports
Conducted RF immunity
IEC 61000-4-6:
10 Vrms with 1 kHz sine-wave 80% AM from 150 kHz 80 MHz
Magnetic field immunity
IEC 61000-4-8:
30A/m long duration at 50 Hz
Enclosure type rating None (open style)
Wiring
- Size
- Category?
Refer to DeviceNet Media Design Installation Guide
2 on communication ports
10-pin Linear plug
- Torque
- Catalog number
0.6 0.8 Nm (5 7 lb-in)
1787-PLUG10R
North American temperature code T5
(1) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring and Grounding Guidelines.
