Features
- Dynamic vibration (IEPE) sensor output
- 80g peak acceleration range
- Frequency response:
- ±10%: 1 to 5,000Hz
- ±3 dB: 0.5 to 10,000Hz
- 22kHz resonance frequency
- 100Ω max output impedance
- 500g peak vibration limit
- 5,000g peak shock limit
- Connector:
- 787B: MIL-C-5015 2-pin, R6 type mating connector, 1/4-28 captive screw
- 787BM8-M12: M12 style output and mating connectors, M8 captive screw
- Hermetic sealing
- PZT ceramic / shear sensing element
The Wilcoxon Sensing Technologies 787B series accelerometer is a low-profile, general purpose industrial sensor. It is constructed with 316L stainless steel, and is case isolated, internally shielded, and hermetically sealed. The 787B model features a 2-pin, MIL-C-5015 style output connector, an R6 type mating connector, and a 1/4-28 captive hex head screw (included) with a 0.046in diameter safety wire hole. The 787BM8-M12 model features a 4-pin, M12 style output connector and M8 thread captive screw (included) for mounting.
The 787B series also features ESD and reverse wiring protection and is manufactured in an ISO 9001 facility.
